Description

Applied Fast Charge Protocols: Samsung Adaptive Fast Charge,USB PD,Other

Brand Name: Aohi

Certification: UL,RoHS,FCC,CE

Display screen: No

GaN: Yes

Input: 100-240V 50/60Hz 3A Max

Item Weight: 11 ounces

Laptops: Compatible with MacBook Pro 16", MacBook Pro 14", MacBook Pro 13", MacBook Air, Dell XPS/Inspiron, HP Elite, Google Pixelbook, Microsoft Surface Book 2, ThinkPad, etc.

Max. Output Power: 120W

Model Number: AOC-C017

Note 1: When multiple devices are connected at the same time, plugging a new device in or unplugging any of the devices from the charger will render a short charging pause for other devices. This short pause is due to the power redistribution of the charger.

Note 2: Please unplug the cable if it is not in use in case the max output power of other ports is restricted.

Note 3: Due to Dells proprietary charging protocl, De XPS 15 (9500/9510) will not be charged at full speed. Only supports up to 5A current.

Other: Compatible with Switch Host, Switch Dock, DJI Mavic 3 / Air 2S, AirPods, Apple Watch, Steam Deck, etc.

Output Interface: 2 C Ports,1 AC

Package Dimensions: 4.69 x 3.98 x 1.38 inches

Phones: Compatible with iPhone 15 Pro/ iPhone 15 Plus/ iPhone 15/ iPhone 14/iPhone 14 Pro/iPhone 14 Pro Max/ 13 / 13 Mini / 13 Pro / 13 Pro Max, iPhone 12 / 12 mini / 12 Pro / 12 Pro Max, iPhone SE (2nd generation), iPhone 11 / 11 Pro / 11 Pro Max, iPhone XS / XS Max / XR / X, iPhone 8 Plus; Samsung Galaxy S23 Ultra/S23 / S22+ / S21 / S21+/ S20/ S20+/ S20 Ultra/ S10/ S10e/ S10+/Note 20 Ultra/ Note 20/ Note 10/ Note9/ Note 8; Google Pixel/ Pixel 3XL/ 3/ 2XL/ 2, Sony Xperia, LG G7 / V30+, and more.

Protection: Input Overvoltage Protection, Output Overcurrent/Overvoltage/Over Temperature/Short Circuit Protection

Protocol: PD3.1(PD3.0PD2.0), QC4+(QC4.0QC3.0QC2.0), PPS, APPLE 2.4A, AFC, FCP,SCP

Quality Certification: CCC,ce

Special features: USB-C1 Up to140W PD3.1 Output, PD 3.1/QC 4.0+/PPS Protocol,, 3-in-1 Fast Multiport Charging, Power Dispenser System, AOHICE 2.0 Thermal Guard System

Tablet: Compatible with iPad 12.9", iPad Pro 11", iPad mini 5, iPad Air 3, etc.

Total Output: 140W Max

Type: Quick charger

USB-A Output: 22.5W Max; 5V/3A, 9V/2A, 12V/1.5A, 10V/2.25A

USB-C1 Output: 140W Max; 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A, 28V/5A, PPS 3.3-21V/5A

USB-C2 Output: 100W Max; 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A, PPS 3.3-20V/5A
